Button Solid

A Button component with a solid background and a label.

Adding a Button Solid

To add a Button solid on the screen:

  • Select the Button Solid component from the Components drawer. You can open the list of components by clicking the + button next to Components.
  • Select the added component in the Components tree.
  • Go to the Config tab (third tab) in the Properties Panel to add a label on the button.

Configuration Properties

PropertyDescription
Component NameTo alter the name of the component. The name is reflected in the Components tree. Defaults to Button Solid.
IconAllows you to select an icon from the icon picker to be displayed on the Button Solid (Icon will be on the left of the Label).
LoadingDisplay a loading indicator in the button in lieu of the icon.
DisabledRemoves button functionality and grays out the label and icon.

Adding an icon to Button Solid

An Icon on the Button Solid component is displayed on the left and before the label. To add an Icon:

  • Select the Button Solid component in the Components tree.
  • Go Configs tab (second tab) in the Properties Panel.
  • Next to the Icon property, open the Icon Picker and select an icon.

Changing Button Dimensions

To change the width and height of the Button Solid:

  • Select the Button Solid component in the Components tree.
  • Go Styles tab (first tab) in the Properties Panel > Size.
  • Set a value for width and height.
  • There are two ways to set these dimensions:
    • To set an exact size, select the pt (default) and enter desired values.
    • To set the dimensions as a % of the screen size, select % instead of pt and enter the desired values.

Changing Border Radius on a Button

To add or change the Border Radius on a Button Solid:

  • Select the Button Solid component in the Components tree.
  • Go Styles tab (first tab) in the Properties Panel > Borders.
  • Add a desired value for the Radius property. By default, the value is 8.

Changing the Background

To add or change the background color of a Button:

  • Select the Button Solid component in the Components tree.
  • Go Styles tab (first tab) in the Properties Panel > Background.
  • Add a desired value for the Color property from the color picker or enter a custom color value in hexadecimal or rgba format.

Changing the Icon and Label color

To add or change the color of Icon or Label on a Button:

  • Select the Button Solid component in the Components tree.
  • Go Styles tab (first tab) in the Properties Panel > Style.
  • Add a desired value for the Color property from the color picker or enter a custom color value in hexadecimal or rgba format.

Under Style, you can also change the font and font size of the label and the icon.
