A basic switch that can be toggled between a selected and unselected state, return a boolean (true or false) value.
Style Properties
Section titled “Style Properties”Style properties allow you to customize the look and feel of the component. Combinations of styles applied to components can be saved as Stylesheets to easily reuse styles throughout your app. Styles can also be set dynamically using Variables. To learn more about all the different styling properties and how they work, take a look at Intro to Styling.
Component Specific Styles
Section titled “Component Specific Styles”| Property | Description |
|---|---|
| Active Track Color | Set the color of the Switch component when its value is true. |
| Inactive Track Color | Set the color of the Switch component when its value is false. |
| Active Thumb Color | Set the color of the thumb when the component value is true. |
| Inactive Thumb Color | Set the color of the thumb when the component value is false. |
Configuration Properties
Section titled “Configuration Properties”| Property | Description |
|---|---|
| Component name | To alter the name of the component. The name is reflected in the Components tree. Defaults to Switch. |
Data Configuration
Section titled “Data Configuration”| Property | Description |
|---|---|
| Disabled | Remove toggle functionality, gray out the switch, and sets it as unselected. You can also initialize it by a boolean value from a data source. Accepted values: true or false. |
| Data Source | Initialize the stateful component with a value from a data source. |
Conditional Display
Section titled “Conditional Display”You can conditionally display a component based on a given condition. Learn more about conditionally displaying components in the Conditional Display doc.
Triggers
Section titled “Triggers”| Trigger name | Description |
|---|---|
| On Value Change | Runs the Actions when the value changes |
